Product Features
integration
Integrated air filtration and pressure regulation functions simplify air path installation and save space.
Single section structure, suitable for compact pneumatic systems.
Efficient filtration
Adopting a 5-40 μ m filtration precision filter element, it effectively removes moisture, oil mist, and particulate impurities.
Transparent polycarbonate (PC) filter cup for easy observation of water accumulation and manual drainage.
Accurate pressure regulation
Adjustable range of 0.05~0.85 MPa, with pressure gauge display, stable output pressure.
Suitable for stable gas supply needs of pneumatic tools, cylinders, and other equipment.
Pressure resistant and durable
Aluminum alloy valve body, corrosion-resistant and lightweight.
NBR/FKM sealing ring, oil and high temperature resistant, suitable for industrial environments.
Easy installation
Standard G1/4 ", G1/2" or G3/8 "interfaces (depending on the model).
It can be directly installed at the front end of the air pump or pneumatic equipment.
Technical Parameter
Parameter specifications
Model AW2000-02 (specific brands may vary, such as Airtac, SMC, Festo)
Interface size G1/4 ", G1/2" or G3/8 "(common)
Working pressure range 0.15~1.0 MPa (maximum pressure resistance 1.5 MPa)
Pressure regulation range 0.05~0.85 MPa (lockable adjustment knob)
Filtering accuracy 5-40 μ m (optional)
Maximum flow rate of 1000~3000 L/min (depending on interface size)
Working temperature -10 ° C~+60 ° C (high temperature resistant models can reach+80 ° C)
The capacity of the filter cup is approximately 100-200 mL (depending on the model)
Material: Valve body: Aluminum alloy/Filter cup: PC (transparent)/Seal: NBR or FKM
Protection level IP65 (dustproof and waterproof)
Typical applications
✔ Post stage purification of air compressor (removing water, oil, and impurities)
✔ Pneumatic tool air supply (such as nail guns, spray guns, polishing machines)
✔ Automation equipment (front-end protection for cylinders and solenoid valves)
✔ Spray painting and food packaging (in situations where clean compressed air is required)
