Key performance parameters and selection points
1. Core parameters (extended supplement)
Output force/torque:
Need to match the valve torque: 1.5-2 times the valve opening and closing torque to avoid stuck.
Dynamic load: Consider the effects of inertia force and friction.
Response speed:
Influencing factors: air source pressure, cylinder volume, pipeline resistance.
High-speed application: Use large flow solenoid valve and short gas path design.
Repetition accuracy:
Adjustable valve: need to be equipped with a high-precision positioner (such as ±0.1% accuracy).
2. Selection process
Determine the load requirements:
Valve type (rotary/linear), maximum torque/thrust.
Action frequency (e.g., number of actions per minute).
Environmental adaptation:
Temperature range (extreme high/low temperatures require special sealing materials).
Protection class (IP65/IP67 for wet, dusty environments).
Control requirements:
Switching type (solenoid valve only) vs. regulating type (positioner required).
Signal type (pneumatic signal, 4-20 mA, bus communication).
Security redundancy:
Single-acting actuators are used in Fail-Safe scenarios.
Dual-acting actuators need to be equipped with gas storage tanks to ensure short operation after gas cut-off.
